Description:

Control System:

7inch touch screen controller,  -40℃~-86℃ adjustable, controlling precision is 1℃.

Keyboard lock and password protected configuration page, Delayed start and safe stop interval between restart and being terminated.

Audible and visual alarm: High or low temperature alarm, Power failure alarm, Low battery alarm, Door open alarm, Filter blocking alarm, system failure alarm.

Structure Design:

Stainless steel interior, Outer is painted steel panel, 4 units Casters for easy handing.

Front opening lockable door with new ingenious handle, easy open and close.

Vacuum release port.

Adjustable stainless steel shelves with inner insulation doors, double silicon gasket seal.

Two-times foaming technology. 120mm foaming insulation , with VIP insulation board.

With USB store functions.

Optional: Chart recorder, CO2 back up system, storage racks/boxes, Remote alarm system.

Refrigeration System:

Imported famous brand compressor, Lower the noise and reduce the power consumption.

Fan electromotor with internationally famous of Germany EBM.

China Patent technology of mixture refrigerant, specially Single stage refrigeration design.

Parameters:

Model: TS-UL398

Capacity(L): 398

Input power: 1050W

External size (W* D * H) mm: 785x1041x1947

Inside  size (W* D * H) mm: 440x696x1266

Storage temperature (℃): - 40 ℃ ~ -86 ℃

Weight (N.t): 252KG

Racks(5*5): 12

Max Vials (1.5ml): 24300

Applications:

Suitable for blood banks ,hospital, sanitation and antiepidemic stations, electronic industries, university laboratories, military industries, pelagic fishery companies, etc.
