Specifications：

　 ·Assay methods: End Point, Kinetic, Fix time etc.
　 ·Principle: Photoelectric colorimetry
　 ·Light Source: Halogen lamp 12V/20W
　 ·Photometry range: 0~3.2Abs
　 ·Resolution: 0.0001Abs
　 ·Wavelength: 10 wavelengths optional (340nm~800nm)
　 ·Throughput: 300tests/hour
　 ·Reagent tray: 59 reagent positions, 1 detergent position
　 ·Sample tray: 71 sample positions, including detergent, standard, QC, STAT positions
　 ·Reaction tray: 120 reaction cuvettes
　 ·Sample volume: 2~100uL,with 0.1uL increment
　 ·Reagent volume: R1:10~500uL, R2: 10~500uL,with 0.5uL increment
　 ·Minimum reaction volume: 150uL
　 ·Maximum reaction time: 10 minutes
　 ·Water Consumption: 6L/hour under working status
　 ·Clean unit: 8-step auto-washing system with detergent and 37℃ water
　 ·Calibration: Calibration reset, select best test point by reaction curve, no need second calibration Line/non-line;multi-standards assay
　 ·Control rules: Westgard multi-rule, Cumulative sum check, Twin plot 3 level controls for each ifem,analyxing and printing QC analysis diagram
　 ·Temperature control: incubator 37±0.1℃
　 ·Power supply: AC110/230(1±10%)V,50/60Hz,500VA
　 ·Ambient: Operating temperature: 10~30℃
                     Relative humidity: ≤85%
                     Atmospheric pressure: 86~106kPa

Features：

　 ·24 hour non-stop cooling system to ensure reagent at 2-8℃
　 ·Dual-unattached durable ceramic syringes to ensure accuracy & precision
　 ·Collision protection in both vertical and horizontal directions, stop & alarm automatically once touching
barrier, not affect former tests
　 ·Automatic eligible cuvettes detection & selection
　 ·Select best test point by reaction curve, create new factor automatically
　 ·High accurate optical system
　 ·Support LIS interface
