Main features:

* Large LCD display, menu designed for convenient use
* Whole plate washing or single strip washing
* 12-way and 8-way manifold included
* Low residual volume by two pipettes
* Complete bottom washing
* Shaking and dipping function
* Automatic monitoring of vacuum and pressure ,automatic rinse cycle
* Flat, V-bottom or U-bottom plate and strips washing
* Large memory to store up to 48 user programmed wash protocols
* Emergency stop available and liquid warning

Application Tests:

Ø Display unit:              liquid crystal display with four rows of twenty digits
Ø Keyboard:                 8 key membrane keyboard
Ø Manifold:                  8 pins and 12 pins
Ø Residual aspiration volume:  ≤1μL / well
Ø Washing times :             0 to 99 times adjustable
Ø Washing strips:             1 to 12 adjustable
Ø Dipping time:               0~3600s adjustable
Ø Shaking time:               0~600s adjustable
Ø Liquid volume:               50~3000 μL / well
Ø Sipping time:                 0.1~9.9 s
Ø Instrument Size:              448mm（L）×382mm（W）×163mm（H）
Ø Package Dimension：         480mm*540mm*590mm
Ø Net Weight：                 8 kg
Ø Gross Weight:                12kg
Ø Power requirements:          AC 100V~240V,50/60 Hz
Ø Power consumption:          65watts
Ø Operation temperature:      5-40℃
Ø Relative humidity:           <80 %
Ø Fluid reservoir capacity:   wash, rinse, waste, buffer X 2L
Ø Storage Capacity:         More than 120 user defined wash board procedures

Remark:

MR-T00B and MR-T00BN methods：Single point calibration；Broken line regression (point-to-point)；linear regression；index regression；the logarithm regression；the double logarithm regression；Log-logit；power regression

MR-T00BS methods：Single point regression mode；Multi point regression；Linear regression；Exponential Regression；Logarithm Regression；Dual Logarithm Regression；log-logit Regression；Polynomial Regression

MR-T00B Elisa Reader is 10.4 inch color display screem ,windows operating system .

MR-T00BS Elisa Reader is 5.7 inch LCD display screen, sold best and performance stability .

MRT00BNElisa Reader is no display screen ,need connect with computer to operate, we will provide free PC software .Can support windows 7,10 ,xp .
