Multiparameter pocket conductivity meter with a TDS measurement mode, 3 points calibration, setup menu contains 6 optional parameters. Accuracy: 1% F.S. Features: Multiparameter pocket conductivity meter contains the TDS measurement mode. Pl...
Multiparameter pocket conductivity meter with a TDS measurement mode, 3 points calibration, setup menu contains 6 optional parameters. Accuracy: 1% F.S.
Features:
• Multiparameter pocket conductivity meter contains the TDS measurement mode.
• Platinum conductivity cell provides the fast and reliable measurement results.
• 1 to 3 points push-button calibration, automatically recognizes the calibration solutions.
• Automatic Temperature Compensation provides accurate reading over the entire range.
• Auto-Hold feature senses and locks the measurement endpoint.
• Battery indicator shows the remaining battery capacity.
• Auto-Power Off effectively conserves battery life.
• Setup menu allows setting the 6 parameters, including the number of calibration points,
temperature unit, TDS conversion factor, etc.
• Reset feature automatically resumes all settings back to factory default options.
• Replaceable electrode module reduces maintenance and replacement cost.
• Waterproof feature to ensure complete protection in harsh environments.
Applications:
• Water and wastewater treatment
• Research and education
• Environmental monitoring
• Electroplating and printing industry
• Aquaculture and hydroponics
• Beverage industry and other industrial applications
Specifications:
Model |
TS-CT30 |
|
Conductivity |
||
Range |
0~20.00, 200.0, 2000µS/cm, 20.00mS/cm |
|
Accuracy |
±1% F.S |
|
Resolution |
0.01/0.1/1 |
|
Calibration Points |
1 to 3 points |
|
Calibration Solutions |
84µS/cm, 1413µS/cm, 12.88mS/cm |
|
TDS |
||
Range |
0~10.00, 100.0, 1000ppm, 10.00ppt (Max. 20ppt) |
|
Accuracy |
±1% F.S |
|
TDS Factor |
0.1~1.0 (Default 0.5) |
|
Temperature |
||
Range |
0~60°C, 32~140°F |
|
Accuracy |
±1°C |
|
Resolution |
0.1°C |
|
Calibration Points |
1 point |
|
Measurement Units |
°C or °F |
|
General |
||
Temperature Compensation |
0~60°C, 32~140°F, Automatic |
|
Temperature Coefficient |
2%/°C |
|
Compensation Modes |
|
Linear |
Cell Constant |
|
K=1 |
Reference Temperature |
|
25°C |
Data Hold |
|
Manual or Automatic endpoint detection |
Power Off |
|
Manual or Automatic (8 minutes after last key pressed) |
Reset Function |
|
Yes |
Sensor Type |
|
ECSCAN-C1-10K |
Display |
|
LCD |
Power Requirements |
2×1.5V "AAA" batteries |
|
Battery Life |
Approximately 200 hours |
|
Dimensions |
185(L)×40(Dia.)mm |
|
Weight |
100g |
