Semiautomatic Polarimeter
Multiparameter semiautomatic polarimeter contains 4 measurement modes (Optical rotation, specific rotation, concentration and International Sugar Scale). Accuracy: 0.02 degrees. Features: High-performance semiautomatic polarimeter is equippe...
Multiparameter semiautomatic polarimeter contains 4 measurement modes (Optical rotation, specific rotation, concentration and International Sugar Scale). Accuracy: 0.02 degrees.
Features:
• High-performance semiautomatic polarimeter is equipped with a 5.6 inches touch screen.
• Selectable 4 measurement modes, including the optical rotation, specific rotation,
concentration and International Sugar Scale.
• LED provides a long-life light source.
• Built-in temperature sensor automatically senses the temperature of sample chamber.
• Selectable tube length or manually enter the desired values.
• Zero point calibration can be used for adjusting the optical visual field and eliminating the
measurement error.
• Expanded memory stores and recalls up to 100 data sets.
• Stored data can be transferred into computer by USB communication interface.
• Reset feature automatically resumes all settings back to factory default options.
• On-screen operating manual detailedly shows the polarimeter uses.
Specifications:
|
Model |
TS-SP200 |
|
|
Measurement Modes |
Optical Rotation, Specific Rotation, Concentration, ISS (°Z) |
|
|
Range |
±90°, ±130°Z |
|
|
Accuracy |
±0.02°, ±0.05°Z |
|
|
Resolution |
0.005° |
|
|
Calibration Points |
1 to 3 points |
|
|
Light Source |
LED, interference filter |
|
|
Test Tube Length |
50/100/200mm |
|
|
Temperature Range |
0~100°C |
|
|
Temperature Accuracy |
±0.5°C |
|
|
Memory |
Stores up to 100 data sets |
|
|
Output |
USB communication interface |
|
|
Language |
English |
|
|
Display |
5.6 inch TFT touch screen |
|
|
Power Requirements |
AC 220V/50Hz |
|
|
Dimensions |
550(L)×300(W)×220(H)mm |
|
|
Weight |
7.5kg |
